KSB BoosterControl Advanced Installation & Operating Manual page 67

Parameter Description
Set point
3-5-1
Entering the pressure setpoint (system
pressure)
Bandwidth
3-5-3
Bandwidth within which the frequency
inverters remain at the same, constant
speed independent of pressure.
Accumulation press.
3-5-4
Procedure for increasing pressure in the
accumulator before the system stops
Max.set point
3-5-5
Limit value for maximum setpoint
Adapt. setpoint
3-5-9
Date/time-based alternative setpoint
Delta p Dynamic pressure compensation
3-5-10
Quadratic function for correcting the
setpoint
High pressure alarm
3-5-11
Upper limit value for maximum system
pressure
High pressure action
3-5-12
Parameter for selecting action in case of
excessively high system pressure (stop
pumps or output message only)
Low pressure alarm
3-5-13
Lower limit value for minimum system
pressure
Low pressure action
3-5-14
Parameter for selecting action in case of
excessively low system pressure (stop
pumps or output message only)
Shut down RDP
3-5-15
Minimum suction-side pressure limit for dry
running protection
Reset RDP
3-5-16
Suction-side pressure for re-start following
dry running occurrence
Press. Flow Control
3-5-17
Lack-of-water fault is set if setpoint minus
pressure defined is undershot.
Timer settings
3-6
Configuring the time parameters
Factory setting Possible settings
400 0.. 1000
5 0.. 999
30 0.. 999
1000 400.. 1000
400 0.. 1000
0 -999.. 999
1000 400.. 1000
Stop pumps Stop pumps,
message only
0 0.. 400
Stop pumps Stop pumps,
message only
20 0.. 80
80 20.. 999
100 0.. 1000
- -
min. value max. value Read access right Write access right
0 1000 Everybody
0 999 Everybody
0 999 Everybody
400 1000 Everybody
0 1000 Everybody
-999 999 Everybody
400 1000 Everybody
- - Everybody
0 400 Everybody
- - Everybody
0 80 Everybody
20 999 Everybody
0 1000 Everybody
- - Everybody
Customer
Customer
Customer
Service
Customer
Customer
Customer
Customer
Customer
Customer
Customer
Customer
Service
Nobody
