Product Overview

3 Product Overview

3.1 Intended Use

The drive is an electronic motor controller that converts AC mains input into a variable AC waveform output. The frequency
and voltage of the output are regulated to control the motor speed or torque. The drive is designed to:
•
Regulate motor speed in response to system feedback or to remote commands from external controllers.
•
Monitor system and motor status.
•
Provide motor overload protection.
The drive is designed for industrial and commercial environments in accordance with local laws and standards. Depending
on configuration, the drive can be used in standalone applications or form part of a larger system or installation.
NOTICE
In a residential environment, this product can cause radio interference, in which case supplementary mitigation
measures can be required.
Foreseeable misuse
Do not use the drive in applications which are non-compliant with specified operating conditions and environments. Ensure
compliance with the conditions specified in chapter 10 Specifications.

3.2 Power Ratings, Weight, and Dimensions

For enclosure sizes and power ratings of the drives, refer to Table 3.1. For more dimensions, see chapter 10.9 Enclosure
Dimensions.
Enclosure size
55–75 kW
(200–240 V)
110–160 kW
Rated power [kW]
(380–480 V)
75–160 kW
(525–690 V)
IP
NEMA
Type 1/12
Shipping Height
dimensions
Width
[mm (inch)]
Depth
Height
Drive
dimensions Width
[mm (inch)]
Depth
Maximum weight [kg (lb)]
Table 3.1 Power Ratings, Weight, and Dimensions, Enclosure Size D1h–D4h
1) Regen, load share, and brake terminal options are not available for 200–240 V drives.
MG21A502
Operating Guide
D1h D2h
90–160 kW 55–75 kW
(200–240 V) (200–240 V)
200–315 kW 110–160 kW
(380–480 V) (380–480 V)
200–400 kW 75–160 kW
(525–690 V) (525–690 V)
21/54 21/54
Type 1/12
587 (23) 587 (23) 587 (23)
997 (39) 1170 (46) 997 (39)
460 (18) 535 (21) 460 (18)
893 (35) 1099 (43) 909 (36)
325 (13) 420 (17) 250 (10)
378 (15) 378 (15) 375 (15)
98 (216) 164 (362) 98 (216)
Danfoss A/S © 09/2018 All rights reserved.
D3h D4h
90–160 kW
(200–240 V)200–
315 kW
(380–480 V)
200–400 kW
(525–690 V)
20 20
Chassis Chassis
587 (23)
1170 (46)
535 (21)
1122 (44)
350 (14)
375 (15)
164 (362)
D3h D4h
With regeneration or load share
terminals 1)
20 20
Chassis Chassis
587 (23) 587 (23)
1230 (48) 1430 (56)
460 (18) 535 (21)
1004 (40) 1268 (50)
250 (10) 350 (14)
375 (15) 375 (15)
108 (238) 179 (395)
3 3
