Electrical Installation
1260 (49.6)
1
1202 (47.3)
1082 (42.6)
2
1034 (40.7)
1009 (39.7)
0.0
1
Mains terminals
2
Ground terminals
Illustration 5.27 D7h Terminal Dimensions with Brake Option (Front View)
MG21A502
Operating Guide
3
Brake terminals
4
Motor terminals
Danfoss A/S © 09/2018 All rights reserved.
3
4
55
5
5
