Electrical Installation
5.8.7 D7h Terminal Dimensions
1
2
412 (16.2)
372 (14.7)
0.0
1
Mains terminals
2
Brake terminals
Illustration 5.25 D7h Terminal Dimensions with Disconnect Option (Front View)
MG21A502
Operating Guide
3
Motor terminals
4
Ground terminals
Danfoss A/S © 09/2018 All rights reserved.
545 (21.4)
515 (20.3)
3
395 (15.6)
4
5
5
53
