Mechanical Installation
1
Pedestal wall spacer
2
Fastener slots
3
Mounting flange at drive top
4
Mounting holes
5
M10 nuts (fasten to threaded posts)
Illustration 4.6 Pedestal Installation in D7h/D8h Drives
MG21A502
Operating Guide
200 (7.9)
6
7
8
9
10
Danfoss A/S © 09/2018 All rights reserved.
Back flange of pedestal
M5 screw (fasten through back flange)
Front flange of pedestal
Front cover plate of pedestal
M5 screw (fasten through front flange)
1
2
3
4
4
4
5
6
7
8
9
10
21
