Control Channel Functions - Mode 4
DMX Channel
12
VLX3 Wash Luminaire Operational Modes (from Control
Channel Settings)
Display On / Off (All Modes)
With the display on, the backlight timer will control how long the luminaire's display backlight will
stay on. Also, the display LED indicators (Power, Tx, Rx and Error) will illuminate normally. With
display off, the backlight will stay off as will the LED indicators.
Reset All to Defaults (All Modes)
Reset to defaults, when selected via control console and channel, will restore all factory default
settings but will not affect the starting DMX address.
Quiet Mode (All Modes)
Quite Mode lowers LED output levels for low noise operation. In Quiet Mode, LED junction
temperatures are lowered and fan noise set to minimum. Fans will still vary in speed, but will not
exceed the set (lower noise) limit.
Level Light Mode (All Modes)
Level Light Mode maintains a reduced LED output to keep various fixtures from operating at different
levels depending upon thermal situations. The fans will run full speed, regardless of junction
temperatures.
02.97 03.000 1 A
Table 3-8: Control Channel Functions - Mode 4
Control Channel Function
Default Setting on Console
Display On / Off
Reset All to Defaults**
Quiet Mode
†
Level Light Mode
†
Constant Fans Mode
†
Normal Mode
†
Dimmer Curve LINEAR
†
Dimmer Curve SQUARE LAW
Full Luminaire Reset
Color Calibration OFF
†
Color Calibration ON
†
Manual Color Adjust ENABLE†
Manual Color Adjust STORE†
Notes:
** When resetting to defaults, the following will be enabled on the luminaire:
• Normal Mode
• Dimmer Curve SQUARE LAW
• Color Calibration ON
† These settings require the Command Lock in Menu to be set to OFF in order to change on Control Chan-
nel. Resetting to defaults will turn Command Lock OFF.
1 7 Dec emb er 2 012
O : DMX O
PERATION
Control Channel DMX Value
†
3
PERATION
0
3 - 4
5 - 7
11 - 13
14 - 16
17 - 19
20 - 22
31 - 32
34 - 35
81 - 87
116 - 117
118 - 120
121 - 122
124 - 125
41
