Vari Lite VLX3 User Manual page 47

24 Strobe - LED Engine 2
25 Red 3 - High Byte
26 Red 3 - Low Byte
27 Green 3 - High Byte
28 Green 3 - Low Byte
29 Blue 3 - High Byte
30 Blue 3 - Low Byte
31 White 3 - High Byte
32 White 3 - Low Byte
33 Strobe - LED Engine 3
34 Unused
35 Unused
36 Engine Modifier
02.97 03.000 1 A
Table 3-3: VLX3 Wash Luminaire Mapping Mode 3
0 - 255 0 - 100%
0 - 65535 0 - 100%
0 - 65535 0 - 100%
0 - 65535 0 - 100%
0 - 65535 0 - 100%
0 - 255 0 - 100%
N/A N/A
N/A N/A
0 - 255 0 - 100%
1 7 Dec emb er 2 012
O : DMX O
PERATION
Controls strobe operations as follows:
Open = DMX 0 - 2
Closed = DMX 3 - 5
Slow Rand = DMX 6 - 7
Med Rand = DMX 8 - 10
Fast Rand = DMX 11 - 12
Strobe Range = DMX 13 (slowest) - 127 (fastest)
0 Pulse + Slow Rand = DMX 128 - 129
Pulse + Med Rand = DMX 130 - 131
Pulse + Fast Rand = DMX 132 - 133
Pulse + Range = DMX 134 - 191
Pulse - Slow Rand = DMX 192 - 193
Pulse - Med Rand = DMX 194 - 195
Pulse - Fast Rand = DMX 196 - 197
Pulse - Range = DMX 198 - 255
16-bit control of Red LED (Engine 3) from 0 to
0
full.
16-bit control of Green LED (Engine 3) from 0 to
0
full.
16-bit control of Blue LED (Engine 3) from 0 to
0
full.
16-bit control of White LED (Engine 3) from 0 to
0
full.
Controls strobe operations as follows:
Open = DMX 0 - 2
Closed = DMX 3 - 5
Slow Rand = DMX 6 - 7
Med Rand = DMX 8 - 10
Fast Rand = DMX 11 - 12
Strobe Range = DMX 13 (slowest) - 127 (fastest)
0 Pulse + Slow Rand = DMX 128 - 129
Pulse + Med Rand = DMX 130 - 131
Pulse + Fast Rand = DMX 132 - 133
Pulse + Range = DMX 134 - 191
Pulse - Slow Rand = DMX 192 - 193
Pulse - Med Rand = DMX 194 - 195
Pulse - Fast Rand = DMX 196 - 197
Pulse - Range = DMX 198 - 255
N/A For Future Use
N/A For Future Use
Used for setting fixture into expanded mode for
control of individual LED engines. This channel
also contains individual spin speeds and various
other effects. DMX values as follows:
Combined Engine Control = DMX 0 - 10
Independent LED Control = DMX 11 - 20
LED Virtual Spin CW = DMX 21 - 50 (Fast to
Slow)
LED Virtual Spin STOP = DMX 51 - 53
0
LED Virtual Spin Counter CW = DMX 54 - 83
(Slow to Fast)
Stop - Independent Engine Data = DMX 84 - 86
LED Pile-On Spin CW = DMX 87 - 116
(Fast to Slow)
LED Pile-On STOP = DMX 117 - 119
LED Pile-On Spin Counter CW = DMX 120 - 149
Stop - Independent Engine Data = DMX 150 -
152
3
PERATION
31
