12 Control
13 Unused
14 Unused
02.97 03.000 1 A
Table 3-4: VLX3 Wash Luminaire Mapping Mode 4
0 - 255 0 - 100%
N/A N/A
N/A N/A
1 7 Dec emb er 2 012
O : DMX O
PERATION
Used to set different modes, parameters, and
functions of the VLX Wash. Set control channel
value for desired action. Hold value for at least 3
seconds. Set control channel value to 0 without
any scaling.
Default Setting on Console = DMX 0
Display On / Off = DMX 3 - 4
Reset All to Defaults** = DMX 5 - 7
Quiet Mode† = DMX 11 - 13
Level Light Mode† = DMX 14 - 16
Constant Fans Mode† = DMX 17 - 19
Normal Mode† = DMX 20 - 22
Dimmer Curve LINEAR† = DMX 31 - 32
Dimmer Curve SQUARE LAW† = DMX 34 - 35
0
Full Luminaire Reset = DMX 81 - 87
Color Calibration OFF† = DMX 116 - 117
Color Calibration ON† = DMX 118 - 120
Manual Color Adjust ENABLE† = DMX 121 - 122
Manual Color Adjust STORE† = DMX 124 - 125
Notes:
** When resetting to defaults, the following will be
enabled on the luminaire:
- Normal Mode
- Dimmer Curve SQUARE LAW
- Color Calibration ON
† These settings require the Command Lock in
Menu to be set to OFF in order to change on
Control Channel. Resetting to defaults will turn
Command Lock OFF.
N/A For Future Use
N/A For Future Use
3
PERATION
35
