Summary of Contents for Vari Lite VL10 BeamWash

  • Page 1 VARl l � �ll l l lE USER S MANUAL...
  • Page 2 Vari-Lite assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. All information and graphics are property of Vari-Lite, 10911 Petal Street Dallas, Texas 75238 USA. Version as of: 15...
  • Page 3 FOREWORD How To Obtain Warranty Service A copy of the Vari-Lite Limited Warranty was included in the shipping package for this VARI LITE product. To obtain warranty service, please contact customer service at 1-877-VARI-LITE (1-877-827-4548), +1-214-647-7880, or entertainment.service@signify.com request a Return Material Authorization (RMA) for warranty service. You will...
  • Page 4 This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with Vari-Lite system, service, and safety guidelines, may cause harmful interference to radio communications.
  • Page 5 FOREWORD Safety Notices It is extremely important to read ALL safety information and instructions provided in this manual and any accompanying documentation before installing and operating the products described herein. Heed all cautions and warnings during installation and use of this product. Safety symbols used throughout this manual are as follows: CAUTION advising of potential damage to product.
  • Page 6 VARI LITE VL10 BeamWash User’s Manual WARNING: INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST EXCESSIVE EXPOSURE TO UV RADIATION 1. Many VARI LITE luminaires use a lamp that produces UV radiation. DO NOT look directly at lamp. 2. It is hazardous to operate luminaires without lens or shield. Shields, lenses, or ultraviolet screens shall be changed if they have become visibly damaged to such an extent that their effectiveness is impaired.
  • Page 7 FOREWORD Sicherheitshinweise Es ist äußerst wichtig, ALLE Sicherheitsinformationen und -hinweise in diesem Handbuch und dem beiliegenden Informations material zu lesen, bevor Sie die hierin beschriebenen Produkte installieren bzw. bedienen. Halten Sie bei der Installation und dem Einsatz dieses Produkts alle Warnhinweise und Vorsichtsmaßnahmen ein. Folgende Sicherheitssymbole werden in diesem Handbuch verwendet: VORSICHT - weist auf möglichen Produktschaden hin.
  • Page 8 VARI LITE VL10 BeamWash User’s Manual WARNING: HINWEISE ZUM SCHUTZ GEGEN ÜBERHÖHTE UV-STRAHLUNG 1. Viele VARI LITE -Scheinwerfer verwenden die Lampentyp, der UV-Strahlen abgibt. SCHAUEN SIE NICHT direkt in die Lampe. 2. Es ist gefährlich, Leuchten ohne Linsen oder Blenden zu bedienen. Blenden, Linsen oder Ultraviolettschirme müssen ausgetauscht werden, sofern deren Schutzwirkung durch...
  • Page 9 FOREWORD Notes de sécurité Avant de procéder à l’installation des produits décrits dans ce guide et de les mettre en marche, il est extrêmement important de lire TOUS les renseignements et TOUTES les directives de sécurité contenues dans ce guide ainsi que toute documentation jointe. Tenir compte de tous les avertissements et suivre toutes les précautions pendant l’installation et l’utilisation de cet appareil.
  • Page 10 VARI LITE VL10 BeamWash User’s Manual AVERTISSEMENT: DIRECTIVES POUR SE PROTÉGER CONTRE UNE EXPOSITION EXCESSIVE AUX RAYONS UV 1. Plusieurs luminaires VARI LITE utilisent une lampe qui produit des rayons UV. NE PAS fixer son regard sur la lampe. 2. L’utilisation des luminaires sans lentille ou blindage pose des risques. Tous blindages, lentilles ou écrans ultraviolet visiblement endommagés au point que leur efficacité...
  • Page 11 FOREWORD Aviso sobre Seguridad Es muy importante leer TODA la información e instrucciones sobre seguridad que se indica en este manual así como en los documentos adjuntos antes de instalar y operar los productos descritos. Se debe prestar atención a todos los avisos y advertencias durante la instalación y uso de este producto.
  • Page 12 VARI LITE VL10 BeamWash User’s Manual ADVERTENCIA: INSTRUCCIONES PARA PROTECCIÓN CONTINUA CONTRA LA EXPOSICIÓN EXCESIVA DE RADIACIÓN ULTRA VIOLETA 1. Muchas luminarias VARI LITE usan un tipo de lámpara que produce radiación UV. NO mire directamente a la lámpara. 2. Es peligroso operar luminarias sin lentes o protectores. Debe cambiar los protectores, lentes o pantallas ultravioletas si se aprecia que han sido dañadas, y que su efectividad pudiera...

  • Page 13: Table Of Contents

    VL10 BeamWash Beam Control ....................... 32 Strobe ................................32 VL10 BeamWash Gobo/Effects Control ....................33 Overview of Gobos used in VL10 BeamWash ..................33 Gobo Use and Positioning .......................... 33 Fixed Aperture Wheel (Gobo Wheel 1) ....................... 34 Gobo Wheel 2 ............................. 35 VLFX Wheels ..............................
  • Page 14 VL10 BeamWash User’s Manual VARI LITE VL10 BeamWash Timing VL10 BeamWash Timing Channel Information ..................39 Updating Software ................... Software From Luminaire to Luminaire Chapter 4. Menu System Menu Operation What Is the Menu System? ........................52 Controls Operation ............................. 52 Default State ..............................

  • Page 15: Introduction About This Manual

    MSD Platinum 25R 550W Lamp Additional Documentation A service manual, only for Authorized VARI LITE Service Centers and technicians, of the VL10 BeamWash is available in electronic (PDF) format: Luminaire Service Manual Testing, Troubleshooting, Component Replacement and Illustrated Parts Breakdown.

  • Page 16: Text Conventions

    At Vari-Lite, we are committed to providing you the highest quality in customer service. Our comprehensive resources are available to help your business succeed and ensure you get the full benefit of being a Vari-Lite customer. Whether your needs are telephone troubleshooting assistance, product training or technical service, our full-time staff of experienced professionals is on-hand to provide support.

  • Page 17: Chapter 1. Description

    CHAPTER 1. Description This chapter contains descriptions of luminaire features and components, along with a list of accessories which are available. Features Components...

  • Page 18: Features

    VARI LITE VL10 BeamWash User’s Manual Features VL10 BeamWash Standard Features Exclusive new Philips 25R Platinum 550W lamp The brightest fixture in its class 28,000 lumen of output Wide zoom range – 2.2° to 48° Narrowest beam reduction 0.7° Large impact stage presence from a 180mm front...

  • Page 19: Included Items

    The following illustration shows all items included with the luminaire: Hook rails Case SIP Neutrik® powerCON® True1 QuickStart Guide(this document) AC Input Connector Figure 1-1: VL10 BeamWash Included Items Note: * Please Check with the Authorized Vari*Lite dealer for availability on accessories.

  • Page 20: Overview

    VARI LITE VL10 BeamWash User’s Manual Luminaire Overview The following illustration shows the external luminaire components and controls.
  • Page 21 DESCRIPTION:COMPONENTS Notes...

  • Page 22: Chapter 2. Installation

    CHAPTER 2. Installation This chapter contains instructions for installation of the luminaire. It includes connecting power and data, along with instructions for powering up the luminaire for the first time and addressing it within your system. Special Warnings Power and Data Cabling Requirements Installation Procedures Powering Up Addressing...

  • Page 23: Special Warnings

    Special Warnings Exceptional Safety Information for the VL10 BeamWash The light intensity and power density of the VL10 BeamWash exceeds that of other fixtures typically used in this application. The warnings and cautions that follow are critically important to the safe operation of this fixture. This product is for commercial use only by trained professionals only.

  • Page 24: Power And Data Cabling Requirement

    INSTALLATION : POWER AND DATA CABLING REQUIREMENTS Power and Data Cabling Requirements Power The luminaire requires standard AC power distribution from AC100-240V~, 50/60Hz. Current required depends on the AC supply voltage and product model. Note: The mating Neutrik PowerCon connector is supplied, however, you will need to purchase or construct a cable appropriate for your application.

  • Page 25: Dmx Termination Connector

    The terminator is also necessary for software downloads and running tests on multiple luminaires. To construct your own connector, you will need the following components: 5-pin, male XLR connector. Note: A DMX termination connector assembly is available as an accessory from Vari-Lite.

  • Page 26: Installation Procedures

    Installation Procedures Hanging the Luminaire The VL10 BeamWash can be hung horizontally or vertically from any structure designed to work with the type of load created by this moving luminaire. Two mounting truss hooks or other mounting hardware are required. Many compatible truss hooks are available from different manufacturers for your particular needs.
  • Page 27 VARI LITE VL10 BeamWash User’s Manual Figure 2-3: Installing Brackets on Luminaire Enclosure...

  • Page 28: Floor Mounting The Luminaire

    WARNING: Light Beam Projects Intense Heat. Do not illuminate objects within 15 m (49.21 feet) of the VL10 BeamWash. Objects within this range can scorch, melt, or ignite from the heat projected by the light beam.

  • Page 29: Powering Up

    VARI LITE VL10 BeamWash User’s Manual Powering Up Power Up and Configuration Procedure The internal color, gobo, and beam mechanisms will also move through a full range of motion. After calibration, the luminaire head will either stop at its "home" position (which...

  • Page 30: Addressing

    DMX address. Or boot via battery. Press at the same time until display boots Note: The luminaire will require a reset to restore control. See “VL10 BeamWash Control Channel Functions” chapter on page 28 for control channel information on luminaire reset.

  • Page 31: Chapter 3. Operation

    CHAPTER 3. Operation This chapter contains instructions for operating the luminaire using DMX control and for updating the internal software. VL10 BeamWash DMX Channels VL10 BeamWash DMX Mapping VL10 BeamWash Luminaire Timing Updating Software...

  • Page 32: Vl10 Beamwash Dmx Channels

    These tables assume a DMX start address of 1. When a different starting address is used, this address becomes channel 1 function and other functions follow in sequence. Table 3-1: VL10 BeamWash DMX Channel Mapping 16 - Bit Enhanced / 16 - Bit DMX channel’s functions and their values (41/ 36 DMX channels):...
  • Page 33 OPERATION : VL10 BeamWash DMX MAPPING Range Parameter Description Notes Range DMX Defaults* 16 - Bit 16 - Enhanced 162-166 Color 7 LAVENDER Centre 164 185-189 Color 8 GREEN Centre 187 208-212 Color 9 AMBER Centre 210 Color 10 CONGO BLUE Centre...
  • Page 34 VARI LITE VL10 BeamWash User’s Manual Range Parameter Description Notes Range DMX Defaults* 16 - Bit 16 - Enhanced 61 - 65 Aperture CLOVER 66 - 225 Reserved Gobo Wheel Used as a control channel for 0 - 255 0-100%...
  • Page 35 OPERATION : VL10 BeamWash DMX MAPPING Range Parameter Description Notes Range DMX Defaults* 16 - Bit 16 - Enhanced Gobo 1 Rotate CIRCLE SPACE 51 - 55 VL10 Gobo 2 Rotate DOUBLE 3 HOLE 56 - 60 VL10 61 - 65...
  • Page 36 VARI LITE VL10 BeamWash User’s Manual Range Parameter Description Notes Range DMX Defaults* 16 - Bit 16 - Enhanced Control Gobo Wheel 1 (Channel 17). Gobo Selection using shortest 0 - 5 (quickest) path. Gobo Selection using normal 6 - 10 (longest) path.
  • Page 37 OPERATION : VL10 BeamWash DMX MAPPING Range Parameter Description Notes Range DMX Defaults* 16 - Bit 16 - Enhanced Animation Wheel 1 Rotation 51 - 55 CONCENTRIC Animation Wheel 1 Rotation ON 56 - 60 THE ROCK 61 - 65...
  • Page 38 VARI LITE VL10 BeamWash User’s Manual Range Parameter Description Notes Range DMX Defaults* 16 - Bit 16 - Enhanced Gobo Shake Normal Path (Slow to 121 - 150 Fast) Gobo Twist Shortest Path (Slow to 151 - 180 Fast) Gobo Twist Normal Path (Slow to...
  • Page 39 OPERATION : VL10 BeamWash DMX MAPPING Range Parameter Description Notes Range DMX Defaults* 16 - Bit 16 - Enhanced 32781 - 65535 Rotate Slow to Fast >>> Frost 1 Linear control of frost mechanism 0-255 0-100% from out (DMX 0) to...
  • Page 40 VARI LITE VL10 BeamWash User’s Manual Range Parameter Description Notes Range DMX Defaults* 16 - Bit 16 - Enhanced Beam Adjustment of fixture timing to 0 - 255 Timing control beam shaping mechanisms. - See Timing Channel Chart in User...
  • Page 41 OPERATION : VL10 BeamWash DMX MAPPING Range Parameter Description Notes Range DMX Defaults* 16 - Bit 16 - Enhanced 81 - 85 Reserved Values 86 - 90 Reserved Values 91 - 95 Reserved Values 96 - 100 Reserved Values 101 - 105...

  • Page 42: Vl10 Beamwash Control Channel Functions

    VARI LITE VL10 BeamWash User’s Manual VL10 BeamWash Control Channel Functions Control channel functions allow special actions such as reset and partial recalibration. These must be executed with zero time transition or with timing disabled. Discrete values must be used;...
  • Page 43 OPERATION : VL10 BeamWash DMX MAPPING Range Parameter Range % Defaults* Description Notes 16 - Bit 16 - Bit Enhanced 81 - 85 Reserved Values 86 - 90 Reserved Values 91 - 95 Reserved Values 96 - 100 Reserved Values...

  • Page 44: Vl10 Beamwash Dmx Mapping

    VARI LITE VL10 BeamWash User’s Manual VL10 BeamWash DMX Mapping VL10 BeamWash Color Control The luminaire’s color system is composed of a CMY color mixing mechanism and one color wheel. The follow sections describe these components. Color Mixing The color mixing mechanism is made up of three graduated color flags: cyan, magenta and yellow.

  • Page 45: Color Wheels Dmx Map

    OPERATION : VL10 BeamWash DMX MAPPING Table 3-4: VL10 BeamWash Color Wheel Standard Configuration Chart Position Color Filter Part Number 6.03.05.03.1314 Drk Blue 6.03.05.03.2764 Yellow 6.03.05.03.1322 Kelly Green 6.03.05.03.2695 Magenta 6.03.05.03.1317 6.03.05.03.2698 Lavender 6.03.05.03.2705 Green 6.03.05.03.2706 Amber 6.03.05.03.2694 Congo 6.03.05.03.2765...

  • Page 46: Vl10 Beamwash Beam Control

    Beam Adjustment of fixture timing to control beam shaping 0 - 255 Timing mechanisms. - See Timing Channel Chart in User Manual Strobe Table 3-7: VL10 BeamWash DMX Map for Strobe Range Parameter Defaults Description Channel Strobe 0 - 255 Control Channel for strobing functions.

  • Page 47: Vl10 Beamwash Gobo/Effects Control

    Gobo Use and Positioning Vari-Lite has purposely selected a set of standard gobos and gags for this fixture and positioned them within the fixture to offer optimum versatility / performance. The gobos supplied - in the standard factory configuration - have been tested in their respective original positions to protect their service life.

  • Page 48: Fixed Aperture Wheel (Gobo Wheel 1)

    VARI LITE VL10 BeamWash User’s Manual Fixed Aperture Wheel (Gobo Wheel 1) Fixed Aperture wheel have twelve slots, plue one open. Figure 3-3 illustrates the standard gobo configurations: Figure 3-3: Gobo Wheel 1...

  • Page 49: Gobo Wheel 2

    Rotating gobo wheel have eight slots, plus one open. Figure 3-4 illustrates the standard gobo configurations: Figure 3-4: Gobo Wheel 2 For each wheel and their associated standard gobo, refer to Table 3-8 Table 3-8: VL10 BeamWash Gobo Wheel 1 Standard Configuration Chart Position Gobo Style Part Number...

  • Page 50: Vlfx Wheels

    VLFX Wheel have five slots, plus one open. Figure 3-5 illustrates the standard gobo configurations: Figure 3-5: VLFX Wheel For each wheel and their associated standard gobo, refer to Table 3-9 Table 3-9: VL10 BeamWash Gobo Wheel 2 Standard Configuration Chart Position Gobo Style Part Number...

  • Page 51: Index And Rotation

    Spins are variable from DMX 0-126 for CCW fast to slow, and 129-255 for CW slow to fast. The Gobo Index function utilizes 8-bit control which offers enhanced resolution whether in INDEX or ROTATE mode. Table 3-10: VL10 BeamWash DMX Map for Gobo Wheel 2 Defa Desc...
  • Page 52 VARI LITE VL10 BeamWash User’s Manual Table 3-10: VL10 BeamWash DMX Map for Gobo Wheel 2 Gobo 2 16-bit control of index and rotation of gobo 0 - 65535 0-100% 32767 Rot/Index wheel 1. High Byte Low Byte 0 - 32756 Rotate Slow to Fast <<<...

  • Page 53: Vl10 Beamwash Timing

    "steppy" in console timed moves. Note: Some parameters have been excluded from the timing channels. Wheel spin and gobo rotation rate changes are not affected by timing channels. Table 3-12: VL10 BeamWash Channel Function / Timing Channel Relationship Para Range...
  • Page 54 VARI LITE VL10 BeamWash User’s Manual Note: The particular storing syntax for your console, as well as instructions on how to write part cues, can be found in the operation manual for that console. To use these channels, you must: Step 1.
  • Page 55 OPERATION : VL10 BeamWash DMX MAPPING Table 3-13:Timing Channels Map (Continued) DMX Value % Values Time (sec) 10.2 10.4 10.6...
  • Page 56 VARI LITE VL10 BeamWash User’s Manual Table 3-13:Timing Channels Map (Continued) DMX Value % Values Time (sec)
  • Page 57 OPERATION : VL10 BeamWash DMX MAPPING Table 3-13:Timing Channels Map (Continued) DMX Value % Values Time (sec)
  • Page 58 VARI LITE VL10 BeamWash User’s Manual Table 3-13:Timing Channels Map (Continued) DMX Value % Values Time (sec)
  • Page 59 OPERATION : VL10 BeamWash DMX MAPPING Table 3-13:Timing Channels Map (Continued) DMX Value % Values Time (sec)
  • Page 60 VARI LITE VL10 BeamWash User’s Manual Table 3-13:Timing Channels Map (Continued) DMX Value % Values Time (sec)
  • Page 61 OPERATION : VL10 BeamWash DMX MAPPING Table 3-13:Timing Channels Map (Continued) DMX Value % Values Time (sec) Follows Cue Data...

  • Page 62: Updating Software

    VARI LITE VL10 BeamWash User’s Manual Updating Software Transferring Software From Luminaire to Luminaire It is possible to transfer specific software versions between luminaires. As in the case of installing new software versions, multiple luminaires can be programmed at the same time if they are data linked together (refer to “Connecting Data and Power”...
  • Page 63 OPERATION : VL10 BeamWash DMX MAPPING A DMX termination connector is used in this process. Refer to page 16 for more information regarding the construction of this connector. Figure 3-6: Software Transfer Setup Transfer Procedure This procedure is used to transfer software versions between luminaires.
  • Page 64 VARI LITE VL10 BeamWash User’s Manual Notes...

  • Page 65: Chapter 4. Menu System

    CHAPTER 4. Menu System This chapter contains instructions for operating the luminaire using the Menu Display feature. Menu Operation Menu Functions Self-Tests...

  • Page 66: Menu Operation

    VARI LITE VL10 BeamWash User’s Manual Menu Operation What Is the Menu System? The menu system is a programmable set of commands used to configure, address, operate, and test the luminaire. The menu system is controlled at the Menu Display available at the enclosure input panel.

  • Page 67: Default State

    MENU SYSTEM : MENU OPERATION Default State The menu display’s default state during normal operation is to display the DMX address. After 40 seconds of inactivity at the display, it will change to the default state. After longer periods of inactivity, the menu display will switch to its off state. The default state for this feature is 30 seconds, however, different time lengths can also be programmed.

  • Page 68: Menu Functions

    For easy reference, each possible menu item is listed alphabetically in the first column by its display abbreviation. The second column follows with a definition of the abbreviation and then a third column provides an explanation of its purpose and function. Table 4-1: VL10 BeamWash Menu System Chart Address 001~512...
  • Page 69 MENU SYSTEM : MENU OPERATION Table 4-1: VL10 BeamWash Menu System Chart Status (No Errors... or displays a list of errors) Recalibrate (Fixture) Are you sure? Reboot Fixture Are you sure? Version VXXX MM/DD/YY HH:MM Fixture Hours XXXXXX h Crossload (Software)

  • Page 70: Self-Tests

    VARI LITE VL10 BeamWash User’s Manual Self-Tests Running Parameter Tests The luminaire is capable of running self-tests by using the Testmenu functions. When running tests on multiple luminaires, a DMX termination connector is required at the last luminaire in the link. Refer to “Connecting Data and Power”...
  • Page 71 VARI LITE VL10 BeamWash User’s Manual Notes...

  • Page 72: Appendix A. Luminaire Care And Routine Maintenance

    APPENDIX A Luminaire Care and Routine Maintenance This appendix provides instructions for troubleshooting and routine maintenance which may be necessary during the life of the luminaire. Equipment Handling Troubleshooting Routine Maintenance WARNING: All maintenance procedures are to be performed with power removed from the luminaire.

  • Page 73: Equipment Handling

    VARI LITE VL10 BeamWash User’s Manual Equipment Handling Below are some basic tips and information on handling luminaires and their associated components. Locations/Use VARI LITE luminaires are designed for dry locations only. Exposure to rain or moisture (including, but not limited to, fog machines, misters, etc.,) may damage luminaire.

  • Page 74: Solid State Electronics

    TROUBLESHOOTING AND MAINTENANCE Solid State Electronics Electrostatic Discharge (ESD) Electrostatic discharge (ESD) presents a significant danger to solid state electronic components (semiconductor devices and PC board assemblies). Static electricity can build on a variety of common objects (including people) simply by handling or moving. ESD rarely results in immediate failure of a component, but shows up later as an intermittent problem or severely reduces the life of the component.

  • Page 75: Troubleshooting

    VARI LITE VL10 BeamWash User’s Manual Troubleshooting Error Messages If a problem occurs during luminaire calibration, at the end of the calibration sequence the Menu Display will cycle through any applicable error message(s) until the end of the list is reached.

  • Page 76: Routine Maintenance

    TROUBLESHOOTING AND MAINTENANCE Routine Maintenance Lamp Replacement WARNING:Ensure that power is removed from luminaire when installing lamp. WARNING:The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person. CAUTION: Wear cotton gloves or other covering while installing lamp.

  • Page 77: Gobo Replacement - Gobo Wheels

    Gobo/ Effects Control” on page 33 of this manual. Note: Vari-Lite cannot guarantee the service life of any custom gobos or gags when used in conjunction with this fixture. Owners and users employing custom gobos and gags do so at their own risk.
  • Page 78 TROUBLESHOOTING AND MAINTENANCE Figure A-2: Head Covers – Removal Step 3. If removing gobos via bottom of head assembly, undo fan tray assembly with thumb screw to access. Step 4. Rotate desired gobo wheel until required gobo position is accessible. CAUTION: Do not push on gobo glass.
  • Page 79 VARI LITE VL10 BeamWash User’s Manual Step 5. Remove current gobo by carefully pressing on edges of gobo carrier with fingers, pressing gobo toward front end of luminaire (toward lens), and out of wheel. ROTATING GOBO WHEELS Do not touch glass with bare fingers.

  • Page 80: Cleaning Optics, Filters And Gobos

    TROUBLESHOOTING AND MAINTENANCE Cleaning Optics, Filters and Gobos WARNING: Remove power from luminaire before performing maintenance. WARNING: Acetone is a harsh cleaning agent and solvent. Acetone is very flammable. Please handle acetone according to manufacturer’s safety instructions and precautions. The front lens, optics/color filters, and reflector may require cleaning after extended use. FRONT LENS: Use a isopropyl alcohol with a soft, lint-free cloth to clean the front lens.

  • Page 81: Appendix B. Technical Specifications

    APPENDIX B Technical Specifications VL10 BeamWash PROGRAMMABLE FUNCTIONS Color System Ten color control wheels total. A three filter CMY cross fading system. Zoom Optics Covering a range from 2.3° to 44°. Strobe High-performance dual blade strobe system capable of ultra-fast operation.
  • Page 82 264 V, 50 Hz................701.5 W, 2.798 A, PF 0.949 Control Compatible with a wide variety of DMX512 consoles. DMX Channels Mounting Position: The VL10 BeamWash can be mounted and operated in any orientation. Weight 33.01kg (73.7 lbs) TROUBLESHOOTING AND MAINTENANCE...
  • Page 83 Dimensions...
