Control Channel Functions - Mode 2
DMX Channel
41
02.97 03.000 1 A
Table 3-6: Control Channel Functions - Mode 2
Control Channel Function
Default Setting on Console
Display On / Off
Reset All to Defaults**
Quiet Mode
†
Level Light Mode
†
Constant Fans Mode
†
Normal Mode
†
Dimmer Curve LINEAR
†
Dimmer Curve SQUARE LAW
Full Luminaire Reset
Color Calibration OFF
†
Color Calibration ON
†
Manual Color Adjust ENABLE†
Manual Color Adjust STORE†
Engines Combined#
Engines Independent#
Notes:
** When resetting to defaults, the following will be enabled on the luminaire:
• Normal Mode
• Dimmer Curve SQUARE LAW
• Color Calibration ON
† These settings require the Command Lock in Menu to be set to OFF in order to change on Control Chan-
nel. Resetting to defaults will turn Command Lock OFF.
# This parameter does not require that the value be held for 3-seconds to set. NOTE: In Combined Mode, all
fixtures must be patched as Mode 2 units (41 channel) for proper operation.
1 7 Dec emb er 2 012
O : DMX O
PERATION
Control Channel DMX Value
†
3
PERATION
0
3 - 4
5 - 7
11 - 13
14 - 16
17 - 19
20 - 22
31 - 32
34 - 35
81 - 87
116 - 117
118 - 120
121 - 122
124 - 125
150 - 152
153 - 155
39
