VARI LITE - VLX3 W
15 Engine Modifier
16 Red 1 - High Byte
17 Red 1 - Low Byte
18 Green 1 - High Byte
19 Green 1 - Low Byte
20 Blue 1 - High Byte
21 Blue 1 - Low Byte
22 White 1 - High Byte
23 White 1 - Low Byte
24 Strobe - LED Engine 1
25 Red 2 - High Byte
26 Red 2 - Low Byte
27 Green 2 - High Byte
28 Green 2 - Low Byte
29 Blue 2 - High Byte
30 Blue 2 - Low Byte
31 White 2 - High Byte
32 White 2 - Low Byte
36
L U '
ASH UMINAIRE SER
Table 3-4: VLX3 Wash Luminaire Mapping Mode 4
0 - 255
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 255
0 - 65535
0 - 65535
0 - 65535
0 - 65535
1 7 Dec emb er 2 012
M
S ANUAL
0 - 100% 0
0 - 100% 0
0 - 100% 0
0 - 100% 0
0 - 100% 0
0 - 100% 0
0 - 100% 0
0 - 100% 0
0 - 100% 0
0 - 100% 0
Used for setting fixture into expanded mode for
control of individual LED engines. This channel
also contains individual spin speeds and various
other effects. DMX values as follows:
Combined Engine Control = DMX 0 - 10
Independent LED Control = DMX 11 - 20
LED Virtual Spin CW = DMX 21 - 50 (Fast to
Slow)
LED Virtual Spin STOP = DMX 51 - 53
LED Virtual Spin Counter CW = DMX 54 - 83
(Slow to Fast)
Stop - Independent Engine Data = DMX 84 - 86
LED Pile-On Spin CW = DMX 87 - 116
(Fast to Slow)
LED Pile-On STOP = DMX 117 - 119
LED Pile-On Spin Counter CW = DMX 120 - 149
Stop - Independent Engine Data = DMX 150 -
152
16-bit control of Red LED (Engine 1) from 0 to
full.
16-bit control of Green LED (Engine 1) from 0 to
full.
16-bit control of Blue LED (Engine 1) from 0 to
full.
16-bit control of White LED (Engine 1) from 0 to
full.
Controls strobe operations as follows:
Open = DMX 0 - 2
Closed = DMX 3 - 5
Slow Rand = DMX 6 - 7
Med Rand = DMX 8 - 10
Fast Rand = DMX 11 - 12
Strobe Range = DMX 13 (slowest) - 127 (fastest)
Pulse + Slow Rand = DMX 128 - 129
Pulse + Med Rand = DMX 130 - 131
Pulse + Fast Rand = DMX 132 - 133
Pulse + Range = DMX 134 - 191
Pulse - Slow Rand = DMX 192 - 193
Pulse - Med Rand = DMX 194 - 195
Pulse - Fast Rand = DMX 196 - 197
Pulse - Range = DMX 198 - 255
16-bit control of Red LED (Engine 2) from 0 to
full.
16-bit control of Green LED (Engine 2) from 0 to
full.
16-bit control of Blue LED (Engine 2) from 0 to
full.
16-bit control of White LED (Engine 2) from 0 to
full.
