VARI LITE - VLX3 W
23 Control
24
L U '
ASH UMINAIRE SER
Table 3-1: VLX3 Wash Luminaire Mapping Mode 1
0 - 255
1 7 Dec emb er 2 012
M
S ANUAL
0 - 100% 0
Used to set different modes, parameters, and
functions of the VLX Wash. Set control channel
value for desired action. Hold value for at least 3
seconds. Set control channel value to 0 without
any scaling.
Default Setting on Console = DMX 0
Display On / Off = DMX 3 - 4
Reset All to Defaults** = DMX 5 - 7
Quiet Mode† = DMX 11 - 13
Level Light Mode† = DMX 14 - 16
Constant Fans Mode† = DMX 17 - 19
Normal Mode† = DMX 20 - 22
Dimmer Curve LINEAR† = DMX 31 - 32
Dimmer Curve SQUARE LAW† = DMX 34 - 35
Full Luminaire Reset = DMX 81 - 87
Color Calibration OFF† = DMX 116 - 117
Color Calibration ON† = DMX 118 - 120
Manual Color Adjust ENABLE† = DMX 121 - 122
Manual Color Adjust STORE† = DMX 124 - 125
Notes:
** When resetting to defaults, the following will be
enabled on the luminaire:
- Normal Mode
- Dimmer Curve SQUARE LAW
- Color Calibration ON
† These settings require the Command Lock in
Menu to be set to OFF in order to change on
Control Channel. Resetting to defaults will turn
Command Lock OFF.
02 .9 703 .00 01 A
