33 Strobe - LED Engine 2
34 Red 3 - High Byte
35 Red 3 - Low Byte
36 Green 3 - High Byte
37 Green 3 - Low Byte
38 Blue 3 - High Byte
39 Blue 3 - Low Byte
40 White 3 - High Byte
41 White 3 - Low Byte
42 Strobe - LED Engine 3
02.97 03.000 1 A
Table 3-4: VLX3 Wash Luminaire Mapping Mode 4
0 - 255 0 - 100%
0 - 65535 0 - 100%
0 - 65535 0 - 100%
0 - 65535 0 - 100%
0 - 65535 0 - 100%
0 - 255 0 - 100%
1 7 Dec emb er 2 012
O : DMX O
PERATION
Controls strobe operations as follows:
Open = DMX 0 - 2
Closed = DMX 3 - 5
Slow Rand = DMX 6 - 7
Med Rand = DMX 8 - 10
Fast Rand = DMX 11 - 12
Strobe Range = DMX 13 (slowest) - 127 (fastest)
0 Pulse + Slow Rand = DMX 128 - 129
Pulse + Med Rand = DMX 130 - 131
Pulse + Fast Rand = DMX 132 - 133
Pulse + Range = DMX 134 - 191
Pulse - Slow Rand = DMX 192 - 193
Pulse - Med Rand = DMX 194 - 195
Pulse - Fast Rand = DMX 196 - 197
Pulse - Range = DMX 198 - 255
16-bit control of Red LED (Engine 3) from 0 to
0
full.
16-bit control of Green LED (Engine 3) from 0 to
0
full.
16-bit control of Blue LED (Engine 3) from 0 to
0
full.
16-bit control of White LED (Engine 3) from 0 to
0
full.
Controls strobe operations as follows:
Open = DMX 0 - 2
Closed = DMX 3 - 5
Slow Rand = DMX 6 - 7
Med Rand = DMX 8 - 10
Fast Rand = DMX 11 - 12
Strobe Range = DMX 13 (slowest) - 127 (fastest)
0 Pulse + Slow Rand = DMX 128 - 129
Pulse + Med Rand = DMX 130 - 131
Pulse + Fast Rand = DMX 132 - 133
Pulse + Range = DMX 134 - 191
Pulse - Slow Rand = DMX 192 - 193
Pulse - Med Rand = DMX 194 - 195
Pulse - Fast Rand = DMX 196 - 197
Pulse - Range = DMX 198 - 255
3
