Installing in Truss:
Step 1. Using two people, lift luminaire into mounting position.
Step 2. Secure in place with truss hook. Ensure truss hook hardware that locks hook in place (e.g.
wing bolt) is properly tightened and that luminaire is fully supported.
Step 3. Attach safety cable (as required) as follows (refer to
a. Connect one end of cable to luminaire handle.
b. Loop at least once around truss/pipe and attach other end of cable to opposite handle.
Step 4. Connect power and data cables according to procedure given in
Power" on page
WARNING: DO NOT connect or disconnect energized power cable at fixture (under load). Turn off
circuit breaker (or completely de-energize circuit) before connecting or disconnecting power cable at
fixture. Power is only removed from the fixture by disconnecting power cable from source or turning
off source circuit breaker.
Step 5. Be sure pan and tilt locks are disengaged (refer to
details) to allow full head and yoke movement.
Enclosure can be oriented in either
Figure 2-3
direction. See
23.36 in
593.34 mm
3.00 in
76.20 mm
(lens extended)
16
L
U
'
ASH
UMINAIRE
SER
17.
for details.
21.50 in
546.10 mm
18.88 in
479.56 mm
Figure 2-5: Hanging Configuration and Dimensions
1 7 Dec emb er 2 012
M
S
ANUAL
21.50 in
546.10 mm
Figure
2-5):
"Connecting Data and
"Luminaire Overview" on page 7
Safety Cable:
Recommended for hanging installations.
May be required by local codes. Safety
cable is sold separately.
Enclosure Handles
(see note)
NOTE: The enclosure handles
were tested and are in compliance
(for safety cable anchor points) of
the following safety standards:
- IEC / EN 60598-2-17.6.6
- UL1573
for
02 .9 703 .00 01 A
