2.7.

Front Panel

1. Control functions
2. Display
3. Indications
2.8.

Software Spec.

1. Functions:
2. Application software:
--- Vout/ Iout manual adjust by separate encoders (coarse and fine adjustment).
--- OVP/UVL manual adjust by Voltage Adjust encoder.
--- Address selection by Voltage adjust encoder. Range = 0 to 30
--- Go to Local control
--- Output On/Off
--- AC On/Off
--- Foldback control (CV to CC)
--- RS-232/RS-485, IEEE488.2, LAN selection by rear panel DIP-switch
--- Baud rate selection by Current adjust encoder: 1200, 2400, 4800, 9600 and 19200 (RS-232/RS-485
communication only)
--- Re-start modes (Auto-Restart, Safe-Restart)
--- Front Panel Lock/Unlock
--- Parallel Master Slave: H1 = One Master, Zero Slave
H2 = One Master, One Slave
H3 = One Master, Two Slaves
H4 = One Master, Three Slaves
S = Slave
--- Vout: 4 digits, Accuracy: +/-0.5% of rated Vout +/- 1count, Green LED's, Size:10mm
--- Iout: 4 digits, Accuracy: +/-0.5% of rated Iout +/- 1count, Green LED's, Size:10mm
Voltmeter displays voltage at power supply output (local sense) or at load (remote sense).
VOLT Display: PREV setting for Vout, Actual Vout, OVP/UVL settings, SAF/AUT Restart mode, OUT OFF
or fault, LFP/UFP setting, RS-232-RS-485 Address setting, IEEE or LAN Enabled and
Address
CURR Display: PREV setting for Iout, Actual Iout, OVP/UVL, RS-232/RS-485 Baud rate setting, H1-H4 or
S
--- Green LED's: PREVIEW, FOLD, REM/LOCAL, OUT ON/OFF, CC/CV, FINE
Red LED: ALRM (OVP, OTP, FOLD, AC FAIL, ENA, SO)
1. Voltage/Current setting
2. OVP/UVL setting
3. Actual voltage/current setting readback
4. Voltage/current setting readback
5. OVP/UVL setting readback
6. Output On/Off
7. Foldback protection setting
8. Status readback (cc/cv, ovp, otp, foldback, ac fault)
9. Model identification readback
10. Calibration (not user access.)
11. Last setting recall (at power off).
12. Re-start mode setting
13. Front Panel Lock/Unlock
14. IEEE (Optional)
15. Multi-Drop Serial
16. Parallel Master/Slave operation with a single display.
17. LXI Certified LAN (Optional)
18. USB (Optional)
1. Drivers to LabView and LabWindows
2. Simple operating program
30
83532002 Rev C
(DAC-Zero and max points, Display-Zero and max.)
