3. INSTALLATION

3.1.

General

This Chapter contains instructions for initial inspection, preparation for use and
repackaging for shipment. Connection to the PC, setting the communication port and
linking Genesys
Genesys
operation of other instruments. If your equipment is susceptible to magnetic fields,
3.2.

Preparation for Use

In order to be operational, the power supply must be connected to an appropriate AC
power source. The AC source voltage should be within the Power Supply specification.
Do not apply AC Input power before reading Section 3.6 and 3.7 of this User's Manual.
Table 3-1 below, describes the Basic Setup Procedure. Follow the instructions in Table
3-1 in the sequence given to prepare the Power Supply for use.
Step no. Item
1 Inspection
2 Installation
3 AC source
4 Test
5 Load
connection
6 Default setting
3.3.

Initial Inspections

Prior to shipment this Power Supply was inspected and found free of mechanical or
electrical defects. Upon unpacking of the Power Supply, inspect for any damage, which
may have occurred in transit.
The inspection should confirm that there is no exterior damage to the Power Supply such
as broken knobs or connectors and that the front panel and meters face are not
scratched or cracked. Keep all packing material until the inspection has been completed.
If damage is detected, file a claim with the carrier immediately and notify the TDK-
Lambda Americas Inc. Sales or Authorized Service facility nearest you.
TM
power supplies are described in Chapter 8.
TM
power supplies generate magnetic fields, which might affect the
do not position it adjacent to the Power Supply.
Initial physical inspection of the Power Supply
Installing the Power Supply,
Ensuring adequate ventilation.
AC source requirements
Connecting the power supply to the AC source
Turn-on checkout procedure.
Wire size selection. Local/Remote sensing. Single or
multiple loads.
The Power Supply setting at shipment.
Table 3-1: Basic Setup Procedure
83532002 Rev C
NOTE
Description
34
Reference
Section 3.3
Section 3.4
Section 3.5
Section 3.6
Section 3.7
Section 3.8
Section 3.9
Section 3.9.6,
4.4.1, 8.2.1
