Ordering information

13.1

Scope of delivery

13.2

Ordering information deTec4 Core

8014253/YST2/2016-04-11 | SICK
Subject to change without notice
Scope of delivery, sender
• Sender
• 2x QuickFix brackets
Scope of delivery, receiver
• Receiver
• 2 x QuickFix bracket
• Test rod with diameter corresponding to the resolution of the safety light curtain
• Label "Important Information"
• Safety note
• Mounting instructions
• Operating instructions for download:
Protective field
height in mm
Part number
300 1211450
450 1211469
600 1211471
750 1211473
900 1211475
1050 1211476
1200 1211478
1350 1211480
1500 1211482
1650 1211484
1800 1211486
1950 1211488
2100 1211490
Table 14: Ordering information deTec4 Core, resolution 14 mm
Protective field
height in mm
Part number
300 1211462
450 1211492
600 1211494
750 1211496
900 1211498
1050 1211499
1200 1211501
1350 1211503
1500 1211505
1650 1211507
1800 1211509
Table 15: Ordering information deTec4 Core, resolution 30 mm
ORDERING INFORMATION
www.sick.com
 Sender
Type code Part number
C4C-SA03010A10000
C4C-SA04510A10000
C4C-SA06010A10000
C4C-SA07510A10000
C4C-SA09010A10000
C4C-SA10510A10000
C4C-SA12010A10000
C4C-SA13510A10000
C4C-SA15010A10000
C4C-SA16510A10000
C4C-SA18010A10000
C4C-SA19510A10000
C4C-SA21010A10000
 Sender
Type code Part number
C4C-SA03030A10000
C4C-SA04530A10000
C4C-SA06030A10000
C4C-SA07530A10000
C4C-SA09030A10000
C4C-SA10530A10000
C4C-SA12030A10000
C4C-SA13530A10000
C4C-SA15030A10000
C4C-SA16530A10000
C4C-SA18030A10000
O P E R A T I N G I N S T R U C T I O N S | deTec4 Core
 Receiver
Type code
1211463 C4C-EA03010A10000
1211470 C4C-EA04510A10000
1211472 C4C-EA06010A10000
1211474 C4C-EA07510A10000
1211515 C4C-EA09010A10000
1211477 C4C-EA10510A10000
1211479 C4C-EA12010A10000
1211481 C4C-EA13510A10000
1211483 C4C-EA15010A10000
1211485 C4C-EA16510A10000
1211487 C4C-EA18010A10000
1211489 C4C-EA19510A10000
1211491 C4C-EA21010A10000
 Receiver
Type code
1211464 C4C-EA03030A10000
1211493 C4C-EA04530A10000
1211495 C4C-EA06030A10000
1211497 C4C-EA07530A10000
1211516 C4C-EA90030A10000
1211500 C4C-EA10530A10000
1211502 C4C-EA12030A10000
1211504 C4C-EA13530A10000
1211506 C4C-EA15030A10000
1211508 C4C-EA16530A10000
1211510 C4C-EA18030A10000
