12
TECHNICAL DATA
12.2

Response time

12.3

Power consumption

54 O P E R A T I N G I N S T R U C T I O N S | deTec4 Core
Housing cross section
Vibration resistance
4)
Shock resistance
5)
Table 9: Operating data
1) Maximum permissible conductor resistances must be observed.
2) The temperature difference between sender and receiver must not exceed 25 K.
3) The cable belonging to the device incl. the associated connection plug must not be flexibly mounted
under -25°C.
4) Test conditions per axis: 1 octave/minute, amplitude: 0.35 mm, 20 sweeps.
5) Test conditions per axis: 500 shocks.
The response time is subject to the following parameters:
•
Resolution
•
Protective field height
Protective field height in mm
300
450
600
750
900
1050
1200
1350
1500
1650
1800
1950
2100
Table 10: Response time dependent on the protective field height
Protective field Typical power consumption of
height in mm sender in W
Resolution
14 mm
300 0.96
450 1.08
600 1.20
750 1.32
900 1.44
1050 1.56
Table 11: Power consumption, sender and receiver
Minimum Typical
31 mm × 34 mm, plus bracket,
ings", page 56
5 g, 10–55 Hz (EN 60068-2-6)
10 g, 16 ms (EN 60068-2-29)
Response time in ms
Resolution 14 mm
11
12
13
13
14
15
16
17
18
19
20
21
22
Typical power consumption of
receiver in W
Resolution Resolution
30 mm 14 mm
0.82 1.92
0.86 2.16
0.91 2.40
0.96 2.64
1.01 2.88
1.06 3.12
Maximum
see "Dimensional draw‐
Resolution 30 mm
10
10
10
11
11
11
12
12
13
13
13
14
14
1)
Resolution
30 mm
1.63
1.73
1.82
1.92
2.02
2.11
