Sender indicators
ERR
PWR
Resolution 14 mm
Figure 2: Sender indicators
The sender has two LEDs, which indicate the operating status:
Position LED color
1 Yellow
2 Red
Complete overview of the LED statuses and their meanings:
page 48.
PRODUCT DESCRIPTION
ERR
PWR
Resolution 30 mm
Indication Labeling
Status indicator PWR
Fault indicator ERR
see "Diagnostic LEDs",
