Figure 1-9
callout 11.
X-Ref Target - Figure 1-9

Kintex-7 FPGA

The KC724 board is populated with the Kintex-7 XC7K325T-3 FFG900E FPGA at U1
(callout 12,
Overview (DS180)

FPGA Configuration

The FPGA is configured in JTAG mode only using one of the following options:
•
•
The FPGA is configured through the Digilent onboard USB-to-JTAG configuration logic
module (U8) where a host computer accesses the KC724 board JTAG chain through a
standard-A plug to micro-B plug USB cable. (callout 13,
The FPGA is configured through the System ACE SD controller by setting the 4-bit
configuration address DIP switch (SW8) to select one of eight bitstreams stored on a Secure
Digital (SD) memory card (see
page
KC724 GTX Transceiver Characterization Board
UG932 (v2.2) October 10, 2014
shows the heatsink fan power connector J121. J121 is shown in
Figure 1-9: Heatsink Fan Power Connector J121
Figure 1-2). For further information on Kintex-7 FPGAs, see 7 Series FPGAs
[Ref 1].
USB JTAG configuration port (Digilent module)
System ACE SD controller
19).
www.xilinx.com
UG932_c1_09_080612
Figure
System ACE SD Configuration Address DIP Switches,
Detailed Description
Figure 1-2 as
1-2).
