Chapter 1: KC724 Board Features and Operation
Table 1-18: VITA 57.1 FMC2 HPC Connections at JA2 (Cont'd)
38
Send Feedback
U1 FPGA Pin
L22 FMC2_LA03_P
L23 FMC2_LA03_N
K23 FMC2_LA04_P
K24 FMC2_LA04_N
L21 FMC2_LA05_P
K21 FMC2_LA05_N
J21 FMC2_LA06_P
J22 FMC2_LA06_N
M20 FMC2_LA07_P
L20 FMC2_LA07_N
J29 FMC2_LA08_P
H29 FMC2_LA08_N
J27 FMC2_LA09_P
J28 FMC2_LA09_N
L30 FMC2_LA10_P
K30 FMC2_LA10_N
K26 FMC2_LA11_P
J26 FMC2_LA11_N
M29 FMC2_LA12_P
M30 FMC2_LA12_N
N27 FMC2_LA13_P
M27 FMC2_LA13_N
N29 FMC2_LA14_P
N30 FMC2_LA14_N
N25 FMC2_LA15_P
N26 FMC2_LA15_N
N19 FMC2_LA16_P
N20 FMC2_LA16_N
U27 FMC2_LA17_CC_P
U28 FMC2_LA17_CC_N
T25 FMC2_LA18_CC_P
U25 FMC2_LA18_CC_N
N21 FMC2_LA19_P
www.xilinx.com
Net Name FMC Pin
KC724 GTX Transceiver Characterization Board
G9
G10
H10
H11
D11
D12
C10
C11
H13
H14
G12
G13
D14
D15
C14
C15
H16
H17
G15
G16
D17
D18
C18
C19
H19
H20
G18
G19
D20
D21
C22
C23
H22
