The GTX transceiver power rails also have corresponding inputs on the GTX transceiver
power terminal block J7 as shown in
a bench-top power supply. J7 is shown in
X-Ref Target - Figure 1-7
Caution!
transceiver rails.
Caution!
of 24A.
Information about the 7 series GTX power supply modules included with the KC724 kit is
available from these vendor websites:
KC724 GTX Transceiver Characterization Board
UG932 (v2.2) October 10, 2014
MGTAVCC_MOD
MGTVCCAUX_MOD
Figure 1-7: GTX Transceiver Power Terminal Block
The 7 series GTX Module MUST be removed when providing external power to the GTX
The GTX transceiver power terminal block J7 has a maximum load current contact rating
• Intersil
• Texas Instruments
• General Electric
www.xilinx.com
Figure 1-7 to supply each voltage independently from
Figure 1-2 as callout 10.
J7
1
2
MTTAVTT_MOD
3
4
5
6
VTT
7
8
9
NC
10
11
NC
12
GND
UG932_c1_07_062912
Detailed Description
15
