Table 1-18: VITA 57.1 FMC2 HPC Connections at JA2 (Cont'd)
KC724 GTX Transceiver Characterization Board
UG932 (v2.2) October 10, 2014
U1 FPGA Pin
N22 FMC2_LA19_N
P23 FMC2_LA20_P
N24 FMC2_LA20_N
P21 FMC2_LA21_P
P22 FMC2_LA21_N
U19 FMC2_LA22_P
U20 FMC2_LA22_N
P29 FMC2_LA23_P
R29 FMC2_LA23_N
P27 FMC2_LA24_P
P28 FMC2_LA24_N
R30 FMC2_LA25_P
T30 FMC2_LA25_N
P26 FMC2_LA26_P
R26 FMC2_LA26_N
R28 FMC2_LA27_P
T28 FMC2_LA27_N
T26 FMC2_LA28_P
T27 FMC2_LA28_N
U29 FMC2_LA29_P
U30 FMC2_LA29_N
V26 FMC2_LA30_P
V27 FMC2_LA30_N
V29 FMC2_LA31_P
V30 FMC2_LA31_N
V25 FMC2_LA32_P
W26 FMC2_LA32_N
V19 FMC2_LA33_P
V20 FMC2_LA33_N
F16 FMC2_PRSNT_M2C_L
(1)
FMC1_FMC2_TCK
U23.8
(1)
U19.2 / U20.1
(1)
U20.2 / U25.3
www.xilinx.com
Net Name
FMC2_TDI
FMC2_TDO
Detailed Description
FMC Pin
H23
G21
G22
H25
H26
G24
G25
D23
D24
H28
H29
G27
G28
D26
D27
C26
C27
H31
H32
G30
G31
H34
H35
G33
G34
H37
H38
G36
G37
H2
D29
D30
D31
