Table 1-17: VITA 57.1 FMC1 HPC Connections at JA2 (Cont'd)
KC724 GTX Transceiver Characterization Board
UG932 (v2.2) October 10, 2014
U1 FPGA Pin
AC12 FMC1_LA10_P
AC11 FMC1_LA10_N
AD9 FMC1_LA11_P
AE9 FMC1_LA11_N
AJ9 FMC1_LA12_P
AK9 FMC1_LA12_N
AG9 FMC1_LA13_P
AH9 FMC1_LA13_N
AK11 FMC1_LA14_P
AK10 FMC1_LA14_N
AH11 FMC1_LA15_P
AJ11 FMC1_LA15_N
AE13 FMC1_LA16_P
AF13 FMC1_LA16_N
AG10 FMC1_LA17_CC_P
AH10 FMC1_LA17_CC_N
AK14 FMC1_LA18_CC_P
AK13 FMC1_LA18_CC_N
AH14 FMC1_LA19_P
AJ14 FMC1_LA19_N
AJ13 FMC1_LA20_P
AJ12 FMC1_LA20_N
AF12 FMC1_LA21_P
AG12 FMC1_LA21_N
AG13 FMC1_LA22_P
AH12 FMC1_LA22_N
AF8 FMC1_LA23_P
AG8 FMC1_LA23_N
AF7 FMC1_LA24_P
AG7 FMC1_LA24_N
AH7 FMC1_LA25_P
AJ7 FMC1_LA25_N
AJ6 FMC1_LA26_P
www.xilinx.com
Net Name FMC Pin
Detailed Description
C14
C15
H16
H17
G15
G16
D17
D18
C18
C19
H19
H20
G18
G19
D20
D21
C22
C23
H22
H23
G21
G22
H25
H26
G24
G25
D23
D24
H28
H29
G27
G28
D26
