Table 1-18: VITA 57.1 FMC2 HPC Connections at JA2 (Cont'd)
KC724 GTX Transceiver Characterization Board
UG932 (v2.2) October 10, 2014
U1 FPGA Pin
H16 FMC2_HB09_N
H11 FMC2_HB10_P
H12 FMC2_HB10_N
A11 FMC2_HB11_P
A12 FMC2_HB11_N
D11 FMC2_HB12_P
C11 FMC2_HB12_N
F15 FMC2_HB13_P
E16 FMC2_HB13_N
E14 FMC2_HB14_P
E15 FMC2_HB14_N
D14 FMC2_HB15_P
C14 FMC2_HB15_N
B13 FMC2_HB16_P
A13 FMC2_HB16_N
D12 FMC2_HB17_CC_P
D13 FMC2_HB17_CC_N
C15 FMC2_HB18_P
B15 FMC2_HB18_N
B14 FMC2_HB19_P
A15 FMC2_HB19_N
M24 FMC2_HB20_P
M25 FMC2_HB20_N
M22 FMC2_HB21_P
M23 FMC2_HB21_N
(1)
U39.11 FMC2_I2C_SCL
(1)
U39.10 FMC2_I2C_SDA
L25 FMC2_LA00_CC_P
K25 FMC2_LA00_CC_N
L26 FMC2_LA01_CC_P
L27 FMC2_LA01_CC_N
J23 FMC2_LA02_P
J24 FMC2_LA02_N
www.xilinx.com
Net Name FMC Pin
Detailed Description
E28
K31
K32
J30
J31
F31
F32
E30
E31
K34
K35
J33
J34
F34
F35
K37
K38
J36
J37
E33
E34
F37
F38
E36
E37
C30
C31
G6
G7
D8
D9
H7
H8
