Active Heatsink Power Connector - Xilinx Kintex-7 FPGA KC724 User Manual

Chapter 1: KC724 Board Features and Operation

Active Heatsink Power Connector

An active heatsink
heatsink and is powered from the 3-pin friction lock header J121
X-Ref Target - Figure 1-8
The fan power connections are detailed in
Table 1-4: Fan Power Connections
16
Send Feedback
(Figure 1-8) is provided for the FPGA. A 12V fan is affixed to the
Figure 1-8: Active FPGA Heatsink
Fan Wire Header Pin
Black J121.1 - GND
Red J121.2 - 12V
Blue J121.3 - NC
www.xilinx.com
(Figure
UG932_c1_08_062512
Table 1-4:
KC724 GTX Transceiver Characterization Board
UG932 (v2.2) October 10, 2014
1-9).
