Audio Connectors (J9 and J10)

Part Description
3.5 mm stereo jack
3.5 mm stereo interconnect
cable
3.5 mm headphones

CAN Connectors (J5 and J11)

Part Description
Modular jack
4-conductor modular jack cable
RS-232 Connector (J6)
Part Description
DB9, female, vertical mount
2m female-to-female cable
ADSP-BF538F EZ-KIT Lite Evaluation System Manual
Manufacturer
A/D ELECTRONICS
Mating Cable (shipped with EZ-KIT Lite)
RANDOM
KOSS
Manufacturer
AMP
Mating Cable
L-COM
Manufacturer
NORCOMP
Mating Cable
DIGI-KEY
Part Number
ST323-5
10A3-01106
UR5
Part Number
5558872-1
TSP3044
Part Number
191-009-213-L-571
AE1020-ND
2-21
