Evaluation Board User Guide

EVALUATION KIT CONTENTS

Table 1 lists the contents of the evaluation kit that are shown in Figure 2.
ADE7169 OR ADE5169 EVALUATION KIT CD
USB-TO-UART CONVERTER
(ADE8052Z-DWDL1)
Table 1. Evaluation Kit Components
Component
EVAL-ADE7169EBZ-2/ADE5169EBZ-2 Board
Evaluation Kit CD
9 V DC Power Adapter
USB-to-UART Connector (ADE8052Z-DWDL1)
1 A replacement or additional USB-to-UART connector can be ordered from Analog Devices using Part Number ADE8052Z-DWDL1.
Figure 2. Evaluation Kit Components
Description
A printed circuit board (PCB) includes a 4-pin UART connector, 3-pin emulator
connector, three push-buttons, and a prototype area.
CD containing all associated software and support documentation for the
evaluation kit.
220 V and 110 V ac to 9 V dc power adapter. Two ac adapters are provided, a
standard 2-pin European Type C plug on one side and a US adapter. A power jack
connector is provided on the other side.
1
USB cable and USB-to-UART PCB. The PCB includes a USB connector at one end and
a 4-pin UART connector at the other end. This PCB provides an isolated connection.
