JUMPER SETTINGS

Table 3. Jumper Settings
Function
P2 UART Power Supply
Selection
LCD Voltage Source Selection
Voltage Channel Input
Current Channel Input
Reference Voltage Source
Selection
1 The second channel current input is only supported by the ADE7169, ADE7166, ADE5166, and ADE5169.
Jumper Option
Pin 1 and Pin 2 of P13 closed
Pin 2 and Pin 3 of P13 closed
Pin 1 and Pin 2 of P6, P7, P8, and P9 closed
Pin 2 and Pin 3 of P6, P7, P8, P9, and P10
closed
JP4, JP5, JP6 and JP9 open
JP1, JP11, JP13, JP14, JP16, and JP19 open;
R16 and R17 removed
JP1, JP11, JP13, JP14, JP16, and JP19 open;
R16 removed; R17 installed
JP1, JP11, JP13, JP16, and JP19 open; R16 and
R17 installed; JP14 closed
JP17 open
Rev. 0 | Page 11 of
Description
P2 UART power supplied by VDD on the board
P2 UART power supplied by VBAT
LCD voltage source using the resistor divider from VDD
LCD voltage source using internal charge pump
Using the on-board resistor divider network for voltage
attenuation
Using shunt but no second current channel
One shunt and one CT for two current channel inputs
Two CTs for two current channel inputs
Using the internal V voltage reference for ADC
REF
