Evaluation Board User Guide

ANALOG INPUTS (P3 AND P11)

Voltage and current signals are connected at the screw terminal, at
P3 and P11, respectively. All analog input signals are filtered
using the on-board antialias filters before being presented to the
analog inputs of the energy metering IC.

CURRENT SENSE INPUTS (P11)

P11 is a three-way connection block that allows the ADE71xx/
ADE75xx/ADE51xx/ADE55xx to be connected to a current
transducer.
The RC networks are the antialias filters that are required by the
on-chip ADCs. The default corner frequency for these low-pass
filters (LPFs) is selected as 4.8 kHz with a resistor of 1 kΩ and a
capacitor of 33 nF).
Rev. 0 | Page 7 of
UG-061
