Process data
Additional Signals
The last part of the process image of the outputs is subdivided into three subsections:
• Control Inputs Overwrite
•
Control Outputs Overwrite
•
Handshake-Signals Overwrite
Description
ControlInput 1
ControlInput 2
ControlInput 3
ControlInput 4
ControlInput 5
ControlInput 6
ControlInput 7
ControlInput 8
DecisionByte
ControlOutput 1
ControlOutput 2
ControlOutput 3
ControlOutput 4
ControlOutput 5
ControlOutput 6
ControlOutput 7
ControlOutput 8
In Up
In Down
In Left
In Right
Out Up
84
Byte Bit Data type
5 0 BOOL
5 1 BOOL
5 2 BOOL
5 3 BOOL
5 4 BOOL
5 5 BOOL
5 6 BOOL
5 7 BOOL
6 BYTE
7 0 BOOL
7 1 BOOL
7 2 BOOL
7 3 BOOL
7 4 BOOL
7 5 BOOL
7 6 BOOL
7 7 BOOL
8 0 BOOL
8 1 BOOL
8 2 BOOL
8 3 BOOL
8 4 BOOL
Comment
