Handover (Handshake-Signals)

The exchange of the required information for the transport of conveyed items between the
MultiControl and an external control takes place via handshake signals.
Out Left = Signal from MultiControl
In Left = Signal to MultiControl
Out Right = Signal from MultiControl
In Right = Signal to MultiControl
PII - Handshake Signals
ID Zone
Out Left Signal: Transfer blocked
Out Right Signal: Transfer blocked
Operating and Programming
Description of the control programs
Up Left
Free Free
Free Free
Free Blocked
Free Blocked
Blocked Free
Blocked Free
Blocked Blocked
Blocked Blocked
Conveyed items for left set to transfer
Conveyed items are to be transferred to the left
Conveyed items for right set to transfer
Conveyed items are to be transferred to the left
Right Decision
Free In order to Left / Right /
Down
Blocked In order to Left / Down
Free In order to Right / Down
Blocked From Up to Down
Free In order to Left / Right
Blocked From Up to Left
Free From Up to Right
Blocked No Transport
PLC-Reference (Read)
Byte Bit
I: 29 6
I: 29 7
41
