Zpa Merge; Timer - Interroll MultiControl Operating And Programming Manual

5.5 ZPA Merge

With the "ZPA Merge" program, conveyed items can be fed into the conveyor line of up to two
additional infeeds.
If an infeed has been cleared in the "Automatic merge" setting, the remaining infeeds are
automatically handled alternately in order to avoid jams (see table "Merge prioritization").

Timer

ID Description
T1 Connection monitoring
T2 Not used
T3 Error reset
T4 Internal conveyed items monitoring
The parameter "Timer 1 - Connection monitoring" should not be changed.
Operating and Programming
Description of the control programs
M3 Motor Left
M4 Motor Right
Default [ms]
100
2000
1000
4000
43
