Interroll MultiControl Operating And Programming Manual page 85

Process data
Description
ControlInput 1
ControlInput 2
ControlInput 3
ControlInput 4
ControlInput 5
ControlInput 6
ControlInput 7
ControlInput 8
DecisionByte
ControlOutput 1
ControlOutput 2
ControlOutput 3
ControlOutput 4
ControlOutput 5
ControlOutput 6
ControlOutput 7
ControlOutput 8
In Up
In Down
In Left
In Right
Out Up
Out Down
Out Left
Out Right
ZoneBusy 1
ZoneBusy 2
ZoneBusy 3
80
Byte Bit Data type
26 0 BOOL
26 1 BOOL
26 2 BOOL
26 3 BOOL
26 4 BOOL
26 5 BOOL
26 6 BOOL
26 7 BOOL
27 BYTE
28 0 BOOL
28 1 BOOL
28 2 BOOL
28 3 BOOL
28 4 BOOL
28 5 BOOL
28 6 BOOL
28 7 BOOL
29 0 BOOL
29 1 BOOL
29 2 BOOL
29 3 BOOL
29 4 BOOL
29 5 BOOL
29 6 BOOL
29 7 BOOL
30 0 BOOL
30 1 BOOL
30 2 BOOL
Comment
Operating and Programming
