Process data
PII, Process Image „I/O Mode Tiny"
Byte Bit Category
0 .0 Sensors
0 .1 Sensors
0 .2 Sensors
0 .3 Sensors
0 .4 Sensors
0 .5 Sensors
0 .6 Sensors
0 .7 Sensors
1 .0 Digital I/O
1 .1 Digital I/O
1 .2 Digital I/O
1 .3 Digital I/O
1 .4 Digital I/O
1 .5 Digital I/O
1 .6 Digital I/O
1 .7 Digital I/O
2 .0 Motors
2 .1 Motors
2 .2 Motors
2 .3 Motors
2 .4 Motors
2 .5 Motors
2 .6 Motors
2 .7 Motors
114
Description
Sensor 1
Sensor 2
Sensor 3
Sensor 4
Sensor 5
Sensor 6
Sensor 7
Sensor 8
I/O 1
I/O 2
I/O 3
I/O 4
Reserve
Reserve
Reserve
Reserve
MotorError 1
MotorOn 1
MotorV2 1
MotorDir 1
MotorError 2
MotorOn 2
MotorV2 2
MotorDir 2
Type Comment
BOOL High = Sensor active (input
type and polarity can be
BOOL
configured)
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
High = Auxiliary
BOOL
input/output 1 active (type
BOOL
and polarity can be
configured)
BOOL
BOOL
BOOL Reserve
BOOL
BOOL
BOOL
BOOL High = Error Motor
BOOL High = Motor on
BOOL High = Speed V2 selected
BOOL High = Reverse main
direction
BOOL High = Error Motor
BOOL High = Motor on
BOOL High = Speed V2 selected
BOOL High = Reverse main
direction
