PII - Motor States (Speed 1 - 4)
ID Description
M1 Motor lift drive
M2 Motor belt drive
M3 Motor conveyor roll
M4 Motor conveyor roll
PIO - Control Inputs Overwrite (Control Input 1 - 4)
ID Description
CI1 Direction selection 1
CI2 Direction selection 2
CI3 Not used
CI4 Not used
Direction selection
CI2 CI1 Description
0 0 From Up to Down
0 1 From Up to Left
1 0 From Up to Right
1 1 Automatic merge
Operating and Programming
Description of the control programs
Connection Connection
MultiControl Interface Box
- Motor 1
- Motor 2
RD 3
RD 4
PLC-Reference
(Read)
Byte
I: 3
I: 4
I: 5
I: 6
PLC-Reference
(Write)
Byte Bit
Q: 5 0
Q: 5 1
Not used
Not used
