Description of the control programs
5.3 ZPA Transfer In
With the "ZPA Transfer In" program, conveyed items can be fed into the conveyor line from up
to two additional infeeds.
The conveyed items are forwarded downstream according to the direction of upstream, left or
right. The signals for the direction selection are set by a PLC.
If an infeed is free in the "automatic merge" setting, the remaining infeeds are automatically
handled alternately in order to avoid jams (see table "merge prioritization").
In "Motorsettings" set motor 1 to "counterclockwise".
Operating and Programming
31
