Process data
PIO, Process Image „Control Mode"
Byte Bit Category
0 .0 Control Inputs
Overwrite
0 .1 Control Inputs
Overwrite
0 .2 Control Inputs
Overwrite
0 .3 Control Inputs
Overwrite
0 .4 Control Inputs
Overwrite
0 .5 Control Inputs
Overwrite
0 .6 Control Inputs
Overwrite
Control Inputs
0 .7
Overwrite
110
Description Type
Control Input 1 BOOL
Control Input 2 BOOL
Control Input 3 BOOL
Control Input 4 BOOL
Control Input 5 BOOL
Control Input 6 BOOL
Control Input 7 BOOL
Control Input 8 BOOL
Comment
Meaning depends on the
selected state table (such as
'stop zone' for the state table
Zone Control)
