Description of the control programs

PLC references according to process image "Universal Full" (see process data)

PII - Motor States (Speed 1 - 4)
ID Description
M1 Motor not used
M2 Motor not used
M3 Motor infeed left
M4 Motor infeed right
PIO - Control Inputs Overwrite (Control Input 1 - 4)
ID Description
CI1 Direction selection 1
CI2 Direction selection 2
CI3 Not used
CI4 Not used
Direction selection
CI2 CI1 Description
0 0 From Up to Down
0 1 From Left to Down
1 0 From Right to Down
1 1 Automatic Merge
44
Connection Connection
MultiControl Interface Box
- -
- -
RD 3 -
RD 4 -
PLC-Reference
(Read)
Byte
I: 3
I: 4
I: 5
I: 6
PLC-Reference (Write)
Byte Bit
Q: 5 0
Q: 5 1
Not used
Not used
