Handover (Handshake-Signals)

The exchange of the required information for the transport of conveyed items between the
MultiControl and an external control takes place via handshake signals.
Out Left = Signal from MultiControl
In Left = Signal to MultiControl
Out Right = Signal from MultiControl
In Right = Signal to MultiControl
PII - Handshake Signals
ID Zone
Out Left Signal: Merge is free
Out Right Signal: Merge is free
PIO - Handshake Signals
ID Zone
In Left Signal: Transfer in from Left
In Right Signal: Transfer in from Right
Operating and Programming
Description of the control programs
Merge is free
Transfer conveyed items from the left
Merge is free
Transfer conveyed items from the right
PLC-Reference (Read)
Byte Bit
I: 29 6
I: 29 7
PLC-Reference (Read)
Byte Bit
Q: 8 2
Q: 8 3
