Bus parameter

SDO-Index 0x4600
Sub-index Description
1 Bus Type
2 IP Configuration
Mode
3 IP Address
4 IP Network Mask
5 IP Gateway
Address
6 IP Address DNS
1
7 IP Address DNS
2
8 IP Host Name
9 IP Domain Name
A ACD Enable
B Quick Start up
Enable
Operating and Programming
Configure MultiControl
Data type Access
USINT R
USINT R/W
UDINT R/W
UDINT R/W
UDINT R/W
UDINT R/W
UDINT R/W
STRING R/W
STRING R/W
BOOL R/W
BOOL R/W
Comment
Used Bus type:
1 = EtherCAT
2 = PROFINET
3 = EtherNet/IP
Configuration mode of the
address:
1 = Static
2 = BOOTP
3 = DHCP
Own IP address
Subnet mask
IP-Address Default
Gateway
IP-Address Domain Name
Server #1
IP-Address Domain Name
Server #2
IP Host Name
IP Domain Name
Identification of address
conflicts (EtherNet/IP)
QuickStart (PROFINET)
