LED displays when using the magnetic sensor
When the magnetic sensor detects the magnet, the "Fault" LED lights up permanently. If the
setting via the magnetic sensor is activated, the "Ready" and "Com" LEDs also flash at 1 Hz.
LED
State
Sensor 1
On
I/O 1
On
I/O 1 +
On
Sensor 3
I/O 1 +
On
I/O 3
I/O 1 +
On
RD 3
I/O 1 +
On
RD 4
RD 1
On
RD 1 +
On
Sensor 3
RD 1 +
On
I/O 3
RD 1 +
On
RD 3
RD 2
On
RD 2 +
On
Sensor 3
RD 2 +
On
I/O 3
RD 2 +
On
RD 3
Operating and Programming
Definition
Setting function 1: Cancel
Setting function 2: Select Sensors
Selection 1 for setting function 2: Sensors PNP Normally
Closed
Selection 2 for setting function 2: Sensors NPN Normally
Closed
Selection 3 for setting function 2: Sensors PNP Normally
Open
Selection 4 for setting function 2: Sensors NPN Normally
Open
Setting function 3: Select bus type
Selection 1 for setting function 3: EtherCAT
Selection 2 for setting function 3: PROFINET
Selection 3 for setting function 3: EtherNet/IP
Setting function 4: Teach-in procedure
Selection 1 for setting function 4: Read motors
Selection 2 for setting function 4: Start teach-in
Selection 3 for setting function 4: Cancel teach-in
Configure MultiControl
7
