Main Menu

Chapter 5. FRONT PANEL OPERATION
The Main Menu for the LBC‐4000 appears as follows:
SELECT: Config Monitor
Faults Util
For quick reference, a description of each of the menu branches follows, and the section in this
appendix (as shown in bold) that addresses use relevant to Redundancy operation. Otherwise,
see Chapter 5. FRONT PANEL OPERATION for complete information on the functionality of
these features:
Menu Branch
Config
Monitor
Faults
Util
Ch 5 / App B Sect Functional Description
5.2.1 / B.3.2
(Configuration) Use to fully configure the LBC-4000.
Use to monitor the alarm status of the unit, to view the log of
5.2.2
stored events, and to display the Receive Parameters screen.
Use to view information on the unit, without having to go into
5.2.3
configuration screens.
(Utility) Use to perform miscellaneous functions, such as
5.2.4 setting the Real-time clock, adjusting the display brightness,
etc.
