LBC-4000 L-Band Up/Down Converter System
Appendix B
B.3.2

CONFIG (Configuration) Menu

CONFIGURE: Conv-A Conv-B
Remote Redund RefAdj
Use the [←][→] arrow keys to select from the submenu choices shown, and then press [ENT].
Each submenu available from the Configuration menu branch is typical for Converter A or
Converter B.
For quick reference, a description of each of the submenu branches follows, and the section in
this appendix (as shown in bold) that addresses use relevant to Redundancy operation.
Otherwise, see Chapter 5. FRONT PANEL OPERATION for complete information on the
functionality of these features:
Submenu
Conv-A
Conv-B
Remote
Redund
RefAdj
Ch. 5 / App. B Sect Description
(Converter Unit A or B) Displays the current configuration
5.2.1.1
of the selected converter, including the frequency,
B.3.4
attenuation, and slope.
(Remote Control) Defines whether the unit is being controlled
5.2.1.2 locally or remotely, and identifies the unit address, interface
type, and rate and format of the baud parameters.
5.2.1.3
(Redundancy) Identifies the redundancy state and mode
B.3.3
(Reference Oscillator Adjustment) Adjusts the reference
5.2.1.4
oscillator.
