LBC-4000 L-Band Up/Down Converter System
Installation
Follow these steps to install the CEFD‐style chassis kit:
Step Task
Use the #10 flat washers, #10 split washers, and #10 hex nuts to secure the #10
1 shoulder screws to the CDM‐800 chassis through the rear right and left side mounting
slots.
Use the #10 rack bracket bolts to install the rear support brackets onto the rack
2
enclosure threaded rear mounting rails.
Mount the unit into the rack enclosure. Ensure that the shoulders of the #10 shoulder
3
screws properly engage into the rear support bracket slots.
