DT-4500 Series C- and Ku-Band Down Converters
Front Panel Operation
6.2.1

Opening Screen

The opening screen displays once you apply power to the unit. The top line
identifies the unit model (e.g., DT-4503C-2). The bottom line displays the
running Firmware Version (this number may vary) and the unit serial number.
Press ENTER to display the Main Menu. Press CLEAR repeatedly from any nested
screen to return to this screen.
The screen shots provided throughout this chapter are applicable to
all DT-4500 Series Down Converters. Any operational restrictions are
noted.
6.2.2

Main Menu

Use the   keys to move the cursor to the desired choice. Press ENTER. The
function of each menu branch is as follows:
• CONFIG (Configuration) Menu Branch – These screens provide selections
for the desired output, local/remote control, redundancy, and fault
recovery operations.
• MONITOR Menu Branch – These screens provide real-time monitoring of
system voltages, unit temperature, IFLO tuning, and Synth tuning.
• FAULTS Menu Branch – The converter displays up to 100 faults, date and
time stamped and stored in memory as they occur.
• PRE-SELECTS Menu Branch – These screens provide configuration and
recall of up to 32 pre-set operating selections.
• UTILITY Menu Branch – These screens permit you to configure such
system functions as the Real-Time Clock, VFD brightness, unit ID, and
firmware loading preferences.
DT_4503C-2
SW VER. #.#.# SN012345678
CONFIG MONITOR
PRE-SELECTS UTILITY
6–7
MN/DT4500.IOM
FAULTS
Revision 2
