7 Reference information
7.1 Main specifications
Light source
External dimensions
Weight
80
Epi (class 1 light source)
Blue Epi light : 460 nm
Green Epi light : 520 nm
Red Epi light : 630 nm
NIR Epi light : 710 nm
Epi and Trans (class 1M light source)
UV Epi light
UV transilluminator
Size
UV transmitted filter size
White transmitted light table
Size
Camera head : 224 x 161 x 252 mm (W/H/D)
IDX : 510 x 730 x 480 mm (W/H/D)
Camera head
IDX
High-sensitivity lens
: 365 nm
: 312 nm
: 322 x 313 x 87 mm
: 200 x 200 mm
: White LED
: 322 x 313 x 87 mm
: 3.4 kg
: 49 kg (not including the light source, lens, and tray)
: 4.5 kg
