After Exposure - GE ImageQuant LAS 4000 Original Instructions Manual

Step
2
2
3

4.4 After exposure

If the ImageQuant LAS 4000 will not be used for some time, it should be switched off as follows.
Step Operation
Select Quit from the File menu.
1
Getting Started with ImageQuant LAS 4000 28-9607-59 AB
Action
Click the Save button or select Save in the File menu to save the image.
Result: The Save dialog opens.
Choose a folder, file name and file format, then click the Save button.
.gel format:
Note:
A file format developed by GE Healthcare. Exposure details are maintained.
.tiff format:
A 16-bit TIFF format suitable for analysis in external software. Exposure
details are not maintained.
Click the Complete button.
Result: The current display returns to the initial screen.
4 Operation
4.3 Performing an exposure
4.3.7 Save the image
59
