4 Operation
4.2 Preparation
4.2.2 Preparing the ImageQuant LAS 4000 for exposure
Changing the light sources
Both trans (transmitted) and epi (incident) light sources are available for exposure with the ImageQuant
LAS 4000.
Type
Transmitted
Incident
Changing the transmitted light source
1 If no transmitted light source is currently in place inside the instrument, proceed to step 4.
2 Turn the lever holding the transmitted light source to unlock it.
3 Pull out the transmitted light source carefully along the guide while holding it with both hands.
4 Push the new transmitted light source in along the guide at the bottom of the IDX.
44
Name Peak wavelength
UV transilluminator 312 nm
White light table -
UV Epi light 365 nm
Blue Epi light 460 nm
Green Epi light 520 nm
Red Epi light 630 nm
NIR Epi light 710 nm
White Epi light -
Getting Started with ImageQuant LAS 4000 28-9607-59 AB
