Phenomenon
ImageQuant LAS 4000 beeps on and
off (three times) and the ERROR LED
lights
ImageQuant LAS 4000 generates a
strange odor
ImageQuant LAS 4000 emits smoke

6.3 Problems with ImageQuant LAS 4000

If the error persists even after the following countermeasures have been taken, fill in the necessary
items and the error code in the Service report fax sheet at the end of the User Manual.
Phenomenon
LED lights on ImageQuant LAS
4000 do not light during startup
diagnosis
The ImageQuant LAS 4000 door
cannot be opened and closed.
The door cannot be locked
The initial diagnosis does not
start even if the power is turned
on
A focused image is not displayed
Getting Started with ImageQuant LAS 4000 28-9607-59 AB
Cause
A hardware error oc-
curred
ImageQuant LAS 4000
failure
ImageQuant LAS 4000
failure
Cause
Power cable installation
failure
Foreign object is present
in the locking section or
door sensor
The locking section is
damaged.
The camera cable is not
connected correctly
Power cable and cam-
era cable connection
failure
Connector connection
failure. Light failure.
Foreign object is present
in the door sensor
Software is not in the
Focusing mode
6.2 Strange sounds or odors are perceived
Countermeasure
See the countermeasures for the SensKey and
SensCode numbers displayed on screen of the
analysis PC in Section6.5 Message "ImageQuant
LAS 4000 hardware error occurred" , on page 69
Turn off the ImageQuant LAS 4000 power
switch immediately and contact your GE
Healthcare representative
Turn off the ImageQuant LAS 4000 power
switch immediately and contact your GE
Healthcare representative
Countermeasure
Connect the power cable correctly
Remove the foreign object
Contact your GE Healthcare represen-
tative
Turn the power off and check the
camera cable connection
Connect the AC power cable and
camera cable correctly
Connect the trans light source by
pushing it all the way until it hits the
other end. Lock the Epi lights in place.
Remove the foreign object
Click the Focusing button in the soft-
ware
6 Troubleshooting
